Cyan Z-Series Engineering and Planning Guide Release 5.0
700-0023-05-00 Rev. 1 © 2013 Cyan, Inc. Proprietary Information Page 209
FP
Flow Point —
An Ethernet Flow Point is a reference point that represents a location of transfer of
connectionless traffic units between topological components. A Flow Point can represent a
location of a physical port or individual sub-flow within a physical port such as a VLAN.
FPP
Flow Point Pool — The termination of a link is called a Flow Point Pool. The FPP describes
configuration information associated with an interface, such as a UNI or NNI.
Frame Short for Ethernet frame
FRU Field Replaceable Unit
FWM
Four-Wave Mixing —
FWM can occur in WDM systems when multiple wavelengths combine to
form new wavelengths. FWM can decrease channel spacing of wavelengths and have high
signal power levels.
GARP Generic Attribute Registration Protocol
GbE Gigabit Ethernet
Gbps Gigabits per second
GE Gigabit Ethernet
GFEC Generic Forward Error Correction
GFP Generic Framing Protocol
GMRP GARP Multicast Registration Protocol
GUI Graphical User Interface
GVRP GARP VLAN Registration Protocol
HALT Highly Accelerated Life Testing
I-SID
Service Instance Identifier — The I-SID is assigned for a service. The service ID is part of the
payload in provider backbone bridges per IEEE 802.1ah. I-SIDs provide additional network
security. I-
SID is a unique identifier used to ensure that users only receive traffic and services for
their respective subscription agreements.
IP
Internet Protocol — Data packets are forwarded from node to node based on the four-byte
destination IP address.
IPMI Intelligent Platform Management Interface
Ingress Frame A service frame sent from the CE to the service provider network.
IS In Service
ITU-T International Telecommunication Union-Telecommunication standards sector
Kbps Kilobits per second
LAC
Lambda Aggregator CWDM — The Cyan Z-Series Lambda Aggregator CWDM terminal
multiplexer module provides up to eight CWDM wavelengths for use in the Cyan Z-Series
multi-layer transport platforms. Each LAC provides optical multiplexing and demultiplexing
capability in the 1470nm to 1610nm band with 20nm spacing.
LACP
Link Aggregation Control Protocol (LACP) is a method of bundling several physical ports
together to form a single logical channel.
LACPDU
Link Aggregation Control Protocol Data Unit —
Two devices exchange LACPDUs in the process
of forming a LAG.
LAD
Lambda Add/Drop — The Cyan Z-Series LAD lambda add/drop DWDM terminal multiplexer
modules are available in four or eight 10G wavelength models for use in the Cyan Z-Series
multi-layer transport platforms. Each LAD provides optical add/drop multiplexing capability in
the 1550nm band across predefined ITU channel designations with 100 GHz spacings.
LAG
Link Aggregation Group — Link Aggregation Group allows for the grouping of Ethernet
interfaces to form a single link layer interface. LAGs provide a logical aggregation of bandwidth
and link redundancy (fault tolerance).
Lambda A wavelength used to carry one or more data channels in a WDM or DWDM system.
