Table 30: Default settings
Default settings
Identifie
r
Description
V
alue
LA Language ITA
SP Setpoint pressure [bar] 3,0
P1 Setpoint P1 [bar] 2,0
P2 Setpoint P2 [bar] 2,5
P3 Setpoint P3 [bar] 3,5
P4 Setpoint P4 [bar] 4,0
FP Test frequency in manual mode 40,0
RC Rated current of electric pump [A] 0,0
RT Direction of rotation 0 (UVW)
FN Rated frequency [Hz] 50,0
OD Type of system 1 (Rigid)
RP Pressure drop for restart [bar] 0,5
AD Address 0 (Auto)
PR Pressure sensor 1 (501 R 25 bar)
MS Measurement system 0 (International)
FI Flow sensor 1 (Flow X3 F3.00)
FD Pipeline diameter [inch] 2
FK K-factor [pulse/l] 24,40
FZ Setting zero flow frequency 0
FT Minimum shutdown flow [ l/min] 5
SO Dry running factor 22
MP Minimum pressure pump stop 0.0
TB Delay for water failure block [s] 10
T1 Shutdown delay [s] 2
T2 Shutdown delay [s] 10
GP Proportional gain coefficient 0,6
GI Integral gain coefficient 1,2
FS Maximum rotation frequency [Hz] 50,0
FL Minimum rotation frequency [Hz] 0,0
NA Active inverters N
NC Simultaneous inverters NA
IC Reserve configuration 1 (Auto)
ET Exchange time [h] 2
CF Carrier [kHz] 5
AC Acceleration 3
AE Anti-blocking function 1(enabled)
I1 Function I1 1 (float)
I2 Function I2 3 (P Aux)
I3 Function I3 5 (Disable)
I4 Function I4 10 (Low press.)
O1 Output 1 function 2
O2 Output 2 function 2
