ENGLISH
76
Figure 12: Menu parameter display
Table 11: Status bar indications
The following can be shown on parameter display pages: numerical values and unit of measurement of
current item, values of other parameters related to setting of current item, graphic bar, lists; see Figure 12.
Status bar indications at the bottom of each page
Identifier Description
GO Electric pump ON
SB Electric pump OFF
FAULT Presence of error that prevents control of the electric pump
