1.2 Technical specifications
Table 1 shows the technical specifications of the products in the range referred to in this manual.
Technical specifications
MCE-55/P MCE-30/P
Inverter power
supply
Voltage [VAC] (Tol +10/-
20%)
380-480 380-480
Phases 3 3
Frequency [Hz] 50/60 50/60
Current [A] 17,0-13,0 11,5-9,0
Inverter output
Voltage [VAC] (Tol +10/-
20%)
0 - V alim. 0 - V alim.
Phases 3 3
Frequency [Hz] 0-200 0-200
Current [A rms] 13,5 7,5
Max. power output [kVA]
(400 Vrms)
7,0 4,0
Mechanical power P2 7,5 CV / 5,5 kW 4,0 CV / 3 kW
Mechanical
specifications
Unit weight [kg]
(excluding packaging)
7,6
Maximum dimensions
[mm](WxHxD)
267x196x352
Installation
Work position Any
IP protection rating 55
Max. ambient temperature
[°C]
50
Max. section of lead
accepted by input and
output terminals [mm²]
4
Min. diameter of cable
accepted by input and
output cable glands [mm]
11
Max. diameter of cable
accepted by input and
output cable glands [mm]
17
Control and
operating
hydraulic
specifications
Pressure regulation range
[bar]
1 – 95% full scale without press.
Options Flow sensor
Sensors
Type of pressure sensors Ratiometric / 4:20 mA
Pressure sensor full scale
[bar]
16 / 25 / 40
Type of flow sensor
supported
5 pulses [Vpp]
Functions and
safety devices
Connectivity

Serial interface
 Multi inverter connection
Safety devices

Dry running
 Current sensitivity on output phases
 Temperature overload on internal electronics
 Abnormal power supply voltages
 Direct shorting between output phases
 Fault on pressure sensor
Table 1: Technical specifications
