13-21
Front Wheel/Front Fork/Steering
● After arranging the cable, install the cable
guide.
● Install the front fork. (⇨13-11)
Cable Guide
Cable Guide
Cable Guide
Cable Guide
Cable Guide
Cable GuideCable Guide
Cable Guide
Cable Guide
Cable Guide
Cable Guide
Cable Guide
Cable Guide
● Install the parts as the below.
- Head light
- Front emblem stay
- Brake caliper
- Front fender
- Front wheel (⇨13-6)
- Cable guide and combimeter
- Handle (⇨13-3)
