Gear Shift Cam

Gear Shift CamGear Shift Cam

Gear Shift Cam

Bolt

BoltBolt

Bolt

Spring

SpringSpring

Spring

Drum Stopper Arm

Drum Stopper ArmDrum Stopper Arm

Drum Stopper Arm

6-8

Clutch, Gearshift

Installation

● Install the drum stopper arm collar, spring,

stopper arm, and bolt. Tighten the bolts.

Torque:1.2kgf-m(12N.m)

Inspection

● Check the gear shift spindle for wear or

damage.

● Inspect the gear shift plate for deformation,

wear, or other damage.

● Check the return spring and gear shift plate

spring for wear or damage.

● Press the stopper arm, and install the cam,

aligning the dowel pin with the gear shift hole.

● Install the thrust washer into the gear shift

spindle.

● Install the gear shift spindle into the crank

case, aligning the teeth of the return spring

with the tappet of the right crank case as

shown.

Part

Collar

Stopper Arm

Thrust Washer

Gear Shift Spindle

Return Spring Teeth

Return Spring TeethReturn Spring Teeth

Return Spring Teeth

Spring

Return Spring

Return SpringReturn Spring

Return Spring

Gear Shift Plant

Gear Shift PlantGear Shift Plant

Gear Shift Plant

Gear Shift Plate

Gear Shift PlateGear Shift Plate

Gear Shift Plate

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
