Web Interface 77
Video set Figure 7-27
Configure video parameters. See Table 7-14 for the details. Step 2
Table 7-14 Video parameter description
Select the video resolution from 1080P, 720P, WVGA, and D1.
Configure the number of frames in 1 second. You can select from 3,
23, and 30. The larger the value is, the smoother the video will be.
Configure the data amount that transmitted in 1 second. You can select
from 256Kbps, 1Mbps, 2Mbps, and 3Mbps. The larger the value is,
the better the video quality will be.
Select the video resolution from CIF, WVGA, QVGA, and D1.
Configure the number of frames in 1 second. You can select from 3,
23, and 30. The larger the value is, the smoother the video will be.
Configure the data amount that transmitted in 1 second. You can select
from 256Kbps, 1Mbps, 2Mbps, and 3Mbps. The larger the value is,
the better the video quality will be.
Changes the value to adjust the picture brightness. The bigger the
value is, the brighter the picture will be, and the smaller the darker. The
picture might be hazy if the value is configured too big.
Changes the contrast of the picture. The bigger the value is, the more
the contrast will be between bright and dark areas, and the smaller the
less. If the value is set too big, the dark area would be too dark and
bright area easier to get overexposed. The picture might be hazy if the
value is set too small.
Makes the color deeper or lighter. The default value is made by the
light sensor, and it is recommended.
Makes the color deeper or lighter. The bigger the value is, the deeper
the color will be, and the lower the lighter. Saturation value doesn’t
change image brightness.
