Daikin DCM601A52 - Page 200

User’s Manual EM11A015B
intelligent Touch Manager
199
4. Display the Attributes screen and set up the group attributes.
(8)
(9)
(10)
Touch the Modify button (8) to display the Text Input dialog where you can change the group
name.
Enter the lower limit room temperature in (9) and the upper limit room temperature in (10) using
the Numerical Input dialog.
In Upper Limit, you can specify a temperature in the 32°C to 50°C range, in increments of 1°C,
while in Lower Limit, you can specify a temperature in the 2°C to 16°C range, in increments of
1°C.
When nished, touch the OK button to return to the Temperature Limit screen.
(12)
(11)
5. To enable the Temperature Limit function for the group selected in (11), select the Enable in the
Activation radio button area (12) button. To disable, select the Disable button.
When nished, touch the Close button and close the screen.
