User’s Manual EM11A015B
intelligent Touch Manager
316
Setting
location
Item Setting details
Possible range [
: Visible, : Conditionally visible, ×: Invisible, Between ( ) : Numerical range]
Remarks
Management point type
AreaIndoor Ventilator Chiller
Dio
Analog
(Ao)
MultiState
(Mo)
Indoor Hydrobox AHU Ventilator D3Chiller InvChiller Chiller
Airow Direction
Airow direction 0
Only Detailed
Setup for
centralized
monitoring.
Airow direction 1
Airow direction 2
Airow direction 3
Airow direction 4
Swing
Timer Extension
ON
× × × × ×
OFF × × × × ×
Setpoint Restriction
Cooling Limit
Enable/Disable
Enable
Detailed Setup
for centralized
monitoring and
Schedule setup
only.
Disable
MAX
Celsius Example: 32°C
Fahrenheit Example: 90°F
MIN
Celsius Example: 16°C
Fahrenheit Example: 60°F
Heating Limit
Enable/Disable
Enable
Disable
MAX
Celsius Example: 32°C
Fahrenheit Example: 90°F
MIN
Celsius Example: 16°C
Fahrenheit Example: 60°F
Ventilator tab
Ventilation Amount
Auto (normal) × × ×
*3*4 × × × × × ×
When Ventilation
Mode is disabled
for the selected
Ventilator
management
point,
the tab itself is
hidden.
Low (normal) × × ×
*3 × × × × × ×
High (normal) × × × *3 × × × × × ×
Auto (fresh up) × × × *3*4*5 × × × × × ×
Low (fresh up) × × × *3*5 × × × × × ×
High (fresh up) × × × *3*5 × × × × × ×
Ventilation Mode
Automatic × × ×
*3 × × × × × ×
ERVentilation × × × *3 × × × × × ×
Bypass × × × *3 × × × × × ×
Dio, Ao, Mo ab
Repeat Mode
Enable/Disable
Enable
Only Detailed
Setup for
centralized
monitoring.
Disable
Interval
1
2
3
4
5
6
7
8
9
10
Analog Example: 0.00
MultiState
Example: Cool/Heat
Recovery
Ao, Mo tab
Analog Example: 0.00 × × × × × × × ×
*6
×
(–9999.99~
9999.99,
w/o unit)
MultiState
Example: Cool/Heat
Recovery
× × × × × × × × ×
*14
×
HW Supply tab
On/Off(Reheat)
Start
Only Detailed Setup
for centralized
monitoring.
Stop
Low Noise
On ×
× × × × × × ×
Off × × × × × × × ×
Storage Water
Setpoint
Celsius Example: 32°C
Only Detailed Setup
for centralized
monitoring.
Fahrenheit Example: 90°F
*1 Not displayed when Setback Control is disabled.
*2 Not displayed when Operation Mode (Dry) is disabled.
*3 Not displayed when Ventilation Mode is disabled.
*4 displayed when Ventilation Amount/Auto Air Volume is disabled.
*5 Not displayed when Ventilation fresh up is disabled.
*6 The value will be displayed in set unit, upper/lower limit range, displayed accuracy.
*7 Displayed in °C or °F depending on the unit selected in the System Settings.
*8 Grayed out when selected Setpoint.
*9 Grayed out when selected Shift Amount.
*10 Start/stop of the water heater cannot be controlled.
*11 Start/stop of the water heater behaves as well as “Permitted”.
*12 The storage setpoint is changeable.
*13 The leaving water setpoint and storage setpoint are out of scope.
*14 MultiState value set up in Service Settings (Mgmt. Point Data Register)
*15 Not displayed for a heating-only Chiller.
*16 Not displayed for a cooling-only Chiller.
