Dalsa Falcon 4-CLHS Series User Manual

Falcon™ 4-CLHS Series Operational Reference  73
Cycling Preset Incremental
Source
cyclingPresetIncrementalSource Specifies the source that increments the currently active
cycling preset.
1.02
Expert
DFNC
None None Feature cyclingPresetCurrentActiveSet is used to select the
current active set.
Valid Frame Trigger ValidFrameTrigger Increment on a Valid Frame Trigger.
Counter 1 End Counter1End Increment on the end of Counter 1.
Start of Frame StartOfFrame Increment on the Start of Frame event.
Line2 Line2
Select Line 2 (and associated I/O control block) to use as
the external increment source.
Cycling Preset Repeater cyclingPresetRepeater Specifies the required number of cycling preset increment
events (generated by the Cycling Preset Incremental
Source) to increment the index of the Cycling Preset Current
Active Set. The difference with cyclingPresetRepeater is that
this feature value is specific to the current cycling set
specified by cP_PresetConfigurationSelector.
1.02
Expert
DFNC
Cycling Preset Reset
Source
cyclingPresetResetSource Specifies the source that resets the currently active cycling
preset to the first set.
1.02
Expert
DFNC
Valid Frame Trigger ValidFrameTrigger Reset when a Valid Frame Trigger occurs.
Counter 1 End Counter1End Reset when Counter 1 ends.
Acquisition End EndOfAcquisition Use End of Acquisition as the reset source. An End of
Acquisition occurs on acquisition stop.
Software Software Use a software command as the reset source.
Cycling Preset Reset cyclingPresetResetCmd
Reset the position of the preset cycling to 1 and the count to
0.
1.02
Expert
DFNC
Cycling Preset Current
Active Set
cyclingPresetCurrentActiveSet Specifies the currently active cycling preset.
1.02
Expert
DFNC
Features Activation
Selector
cP_FeaturesActivationSelector Selects the feature to control by the
cP_FeaturesActivationMode feature.
1.02
Expert
DFNC
Exposure Time ExposureTime The cP_FeaturesActivationMode feature controls the
exposure time.
Exposure Delay ExposureDelay The cP_FeaturesActivationMode feature controls the
exposure delay.
Output Line3 OutputLine3Control
The cP_FeaturesActivationMode feature controls output
line3.
Output Line4 OutputLine4Control The cP_FeaturesActivationMode feature controls output
line4.
Output Line5 OutputLine5Control The cP_FeaturesActivationMode feature controls output
line5.
Output Line6 OutputLine6Control
The cP_FeaturesActivationMode feature controls output
line6.
Multiple ROI MultiROI
The cP_FeaturesActivationMode feature controls the ROI
positions. Only OffsetY is cycled, the height of each ROI is
from multi ROI height on Image Format page. Smaller ROI
id has smaller OffsetY Enable MultiROI mode to activate
cyclying MultiROI.
DigitalGain DigitalGain
The cP_FeaturesActivationMode feature controls the digital
gain.
Features Activation Mode cP_FeaturesActivationMode Enable the selected feature to be part of the cycling. When
activating the selected feature, this will automatically set the
corresponding standard camera feature to read only.
1.02
Expert
DFNC
Off Off Exclude the selected feature from the cycling.
Active Active Include the selected feature in the cycling.
Cycling Preset Selector cP_PresetConfigurationSelector Selects the Cycling Preset to configure its feature. 1.02
Expert
DFNC
