Dalsa Falcon 4-CLHS Series User Manual

74  Operational Reference Falcon™ 4-CLHS Series
Gain cP_DigitalGain Sets the selected gain as an amplification factor applied to
the image. This gain is applied when the current Cycling
index is active.
1.02
Expert
DFNC
Exposure Time cP_ExposureTime Sets the exposure time, in milliseconds. Applicable only
when the Exposure Mode feature is set to Timed. This
setting will be applied when the current Cycling index
occurs.
1.02
Expert
DFNC
Exposure Delay cP_ExposureDelay Sets the exposure delay (in microseconds) for the selected
set.
1.02
Expert
DFNC
ROI Selector cP_MultiROISelector
Select an ROI (Region of Interest) when Multiple ROI Mode
is enabled. Selector range is from 1 to the Multiple ROI
Count Vertical value, or maximum 8 if Multiple ROI Count
Vertical is greater than 8. The height of each ROI is from
Multi ROI Height on Image Format page. Smaller ROI ID has
smaller OffsetY.
1.02
Expert
DFNC
ROI Offset Y cP_MultiROIOffsetY Vertical offset (in pixels) from the origin to the selected ROI
(Region of Interest).
1.02
Expert
DFNC
Line Selector cP_LineSelector Cycling Preset Line Selector.
1.02
Expert
DFNC
Line 3 Line3
Index of the physical line and associated I/O control block to
use. Pin 6 is the Output Signal and Pin 4 is the common
output power on the I/O connector.
Line 4 Line4 Index of the physical line and associated I/O control block to
use. Pin 8 is the Output Signal and Pin 4 is the common
output power on the I/O connector.
Line 5 Line5 Index of the physical line and associated I/O control block to
use. Pin 9 is the Output Signal and Pin 4 is the common
output power on the I/O connector.
Line 6 Line6 Index of the physical line and associated I/O control block to
use. Pin 10 is the Output Signal and Pin 4 is the common
output power on the I/O connector.
Output Line Source cP_OutputLineSource Selects what to output on the selected output line.
1.02
Expert
DFNC
Off Off
Line output is disabled (Tri-State) or Open with Optocoupled
output.
Pulse On: Start of
Exposure
PulseOnStartofExposure Generate a pulse on the ExposureStart event.
Pulse On: End of Timer 1 PulseOnEndofTimer1 Generate a pulse on the end of timer1.
Pulse On: End of Counter 1 PulseOnEndofCounter1 Generate a pulse on the end of Counter1.
Pulse On: Input 1 PulseOnInput1 Generate a pulse on the Input Signal 1 event.
Pulse On: Input 2 PulseOnInput2 Generate a pulse on the Input Signal 2 event.
Software Controlled SoftwareControlled
The OutputLineValue feature changes the state of the
output.
Pulse On: CLHS In PulseOnLinkTrigger0 Generate a pulse on LinkTrigger0 signal.
Exposure Active ExposureActive Generate the Exposure Active state on specific output.
Output Line Value cP_OutputLineValue Cycling Preset Output Line Value. 1.02
Expert
DFNC
Active Active Active sets the output circuit to closed.
Inactive Inactive Inactive sets the output circuit to open.
