1 Getting Started
About the ECHO Series
The ECHO series are portable, digital, handheld ultrasonic thickness gages that are
specifically designed to measure the remaining wall thickness of primarily steel
structures.
Ø Vibralarm (vibrates gage below/above minimum/maximum thickness value)
Ø Illuminating keypad for easy to view go-no-go thickness values
Ø Unique, programmable left-hand/right-hand operation
Ø Up to 20 hour battery life with rechargeable Li-Ion high capacity battery
Ø Small, easy to hold, ergonomic, custom molded, durable case with rubber keypad
designed for IP67 rating
Ø Multiple dual and single element transducer options including high temperature
The ECHO 9 is a base gage in the color family offering a simple user interface packaged
in the same custom molded high-density plastic case with rubber keypad as the other
more sophisticated models. This gage offers reliable, accurate thickness readings on
mostly steel structures with access to only one side. The ECHO series can be easily
upgraded in the field to the add ECHO-9DL, EHCO-9CW, or ECHO-9DLW the live
color waveform (A-scan). We can even add our precision gage mode to allow for 0.0001"
resolution and higher frequency single element probes.
The ECHO-9W is a mid-range model consisting of the most commonly used features in a
thickness gage not requiring a datalogger, but with a live color A-scan. This model offers
gain adjustment, vibrating alarm and illuminating keypad conditions, and automated
transducer replacement notification feature. Like the ECHO 9, this model is field
upgradeable to include a datalogger with color waveform.
Our top of the line model, ECHO-9DLCW, contains all the same features of the ECHO 9
and ECHO-9CW and ECHO-9DL plus:
Ø Live color waveform with gain, range, and rectify adjustments
Ø 1M thickness reading Datalogger using a 32GB micro SD card memory is
essentially “unlimited”
Ø Three pre-set files for linear, grid (row advance), grid (column advance), linear
plus custom point, 2D plus custom point, 3D, boiler, and sequential
Ø B-scan
Ø Custom rubber boot with built-in stand and 4-point chest harness
Ø Probe Zero
Latest Software Updates
Danatronics periodically releases software updates with new and improved gage
functionality and features. You can download the latest standard software at no charge by
going to the ECHO section of www.danatronics.com and clicking on the support tab. Use
