Danatronics, Corp.
82
9 Technical Specifications
Product Specifications for the ECHO 9 Series
Size: 7.25" (184 mm) (L) x 4.00" (101.5 mm) (W) x 2.00" (50.8 mm) (H)
Weight: 1.15 lbs (0.52 kg) with internal Li-Ion battery. 1.0 lb. (0.45 kg) with
optional Alkaline tray including 3 AA batteries
Display: 3.5" high resolution color display, 320 x 240 pixels (1/4 VGA, sunlight
readable, including multiple color choices
Backlight: Light Emitting Diode (LED) backlight, includes variable light
intensity, indoor and outdoor modes
Temperature: (Gage Operating) -4° to 122°F (-20°C to 50°C)
Package: Designed for IP67 rating, custom, splash-proof, high impact plastic
with illuminating rubber keypad for go/no-go testing
Transducer connector type: Lemo 00 (2qty)
Bandwidth: 0.5-30 MHz (-3dB)
Measurement rate: 4 Hz or 25 Hz
Pulser: 150V, Square Wave
Range: Thickness range depends on gage type, probe selection and material
conditions. Typical range in corrosion mode, 0.020" – 23" (0.508 – 584 mm)
Calibration: Cal zero, Cal velocity, Two-point calibration or Auto Calibration
performs a two-point calibration using a 5-step test block
Material Velocity Range: 0.0200 in/usec - 0.7362 in/uS (0.508 – 18.699
mm/uS)
Batteries: Standard 3.7V Li-Ion internally rechargeable battery (16 – 20 hours)
or optional alkaline tray for 3 AA batteries (8 – 12 hours)
Data XL: Interface program to send and receive stored readings, latest firmware
and application set up files as two way communication from ECHO to computer
Stored setups: Storage and recall of calibration and set up files
Memory: Internal memory standard on all models. For datalogger models 2GB
micro SD card standard and expandable up to 32GB
