Table 1. Total-AceXtreme® Series Specifications
PARAMETER MIN TYP MAX UNITS
PHYSICAL CHARACTERISTICS
Package Body Size
324-ball BGA
• BU-67301B0TXL-E02 0.630 x 0.630 x 0.185 in
(16 x 16 x 4.7) (mm)
PHYSICAL CHARACTERISTICS (con’t)
Moisture and ESD Sensitivity
• Moisture Sensitivity Level MSL-3
• Electrostatic Discharge Sensitivity ESD Class 0
Weight
324-ball BGA 0.105 oz
(3) (g)
Notes 1 through 6 are applicable to the Receiver Differential Input Impedance specifications:
1. Specifications include contributions from the transformer, transmitter, and receiver.
2. Impedance parameters are specified directly between pins CHA(B)_1553 and CHA(B)_1553_L of the Total-
AceXtreme hybrid.
3. It is assumed that all power and ground inputs to the package are connected.
4. The specifications are applicable for both unpowered and powered conditions.
5. The specifications assume a 2 volt rms balanced, differential, sinusoidal input. The applicable frequency range is 75
KHz to 1 MHz.
6.
Minimum resistance and maximum capacitance parameters are guaranteed over the operating range, but are not
tested.
7. Typical value for minimum Intermessage gap time. Under software control, this may be lengthened (to 65,535 µs -
message time) in increments of 1 μs.
8. In 0.5 μS increments with a resolution of ±12 μS.9. Measured from mid-parity crossing of Command Word to mid-
sync crossing of RT's Status Word.
9. MIL-STD-1760 requires a 20 V
PK-PK
minimum output on the stub connection.
10. Power supply cu
rrents and power dissipation assume nominal supply voltages, 1.8V and 3.3V. Power Dissipation is
the input power consumption minus the power delivered to the 1553 fault isolation resistors, bus termination
resistors, and the copper losses in the bus coupli
ng transformer. This power is assumed to be approximately 1.5
Watts when the Total-AceXtreme is transmitting.
11. See Section 9 for thermal management requirements at high transmit duty cycles
2.3 Additional Support Documents
This data sheet has been written to address the implementation of the Total-
AceXtreme device on a PC board and specify the device operational and functional
modes. Additional information about MIL-STD-1553, the MIL-STD-1553 core
(AceXtreme), and/or internal register/memory information is available, including the
following:
• The DDC MIL-STD-1553 Designer’s Guide
• MIL-STD-1553B Specification
• MIL-STD-1553 Handbook
