Replacing Consumables
227
Replacing Staple Cartridge (for Finisher-AB1)
When the optional Finisher-AB1 is installed and the staple cartridge needs to be replaced, a
message appears on the touch screen. When the message appears, load a new staple case into
the staple cartridge.
1
Make sure that the machine is not operating,
and open the finisher front cover.
2
Take the staple cartridge out of the finisher.
3
After you take out the staple cartridge, check
inside of the finisher for any remaining staples.
4
Pinch both sides of the empty staple case with
your fingers (1), and remove the staple case
from the cartridge (2).
5
Insert the front side of the new staple case into
the staple cartridge (1), and then push the rear
side into the cartridge (2).
To Next Page
