16 Dell Printer Configuration Web Tool Settings
420
Starting Dell Printer Configuration Web Tool
To use Dell Printer Configuration Web Tool, perform the following procedure on your
computer.
When Login Type is selected on the machine, authentication is required to access the
machine via a web browser.
1
Start a web browser.
2
Enter the machine's IP address or the Internet address in the address box on the web
browser, and press the <Enter> key.
• Example of the IP address entry
http://192.0.2.1/ (IPv4)
http://[2001:DB8::1234] (IPv6)
• Example of the Internet address entry (when the machine's Internet address is
myhost.example.com)
http://myhost.example.com/
Note • If your network uses DNS (Domain Name System) and the machine's host name is registered on the
domain name server, you can access the machine using the Internet address combining the host
name and the domain name. For example, if the host name is "myhost", and the domain name is
"example.com" then the Internet address is "myhost.example.com".
• When specifying a port number, add ":" and the port number after the Internet address.
• If using the Authentication feature on the machine, enter a user ID and passcode in the [User Name]
and [Password] fields. If you are not sure about the user ID and passcode, consult your system
administrator.
The features you can operate vary depending on the system administrator's authority that was given
to a user.
• If communications are encrypted; when the [Enabled] check box is selected under [Security] > [SSL/
TLS Settings] > [HTTP-SSL/TLS Communication] on the [Properties] tab, you must specify an address
that starts with "https" instead of "http" to access Dell Printer Configuration Web Tool.
Example of the IP address entry
https://192.0.2.1/ (IPv4)
https://[2001:DB8::1234] (IPv6)
Example of the Internet address entry
https://myhost.example.com/
If Dell Printer Configuration Web Tool is not displayed, refer to "Dell Printer Configuration Web
Tool Problems" (P.545).
