13 Maintenance
236
Replacing Separator Rollers
There are three separator rollers in the machine which need to be replaced periodically. One
is in the tray and the others are inside the machine. All the separator rollers are replaced in
the same way as described in this section.
Replacing the Separator Roller in a tray
1
Remove the tray from the machine.
Note • Remove all paper or media from the tray
before pulling the tray out of the machine.
2
Turn the separator roller cover to the left to
open it, and then hold the cover.
3
Turn the separator roller cartridge to the right.
4
Pull out the rear axle, then the front axle from
the holes of the tray and remove the separator
roller cartridge.
5
Prepare a new separator roller.
To Next Page
