Replacing Consumables
235
3
Raise the latch of the right hand cover and open
the cover.
4
Unlock the two levers on the transfer roller and
lift up the roller to remove it.
5
Grasp the levers on both sides of the new
transfer roller and align the arrows on the
transfer roller with the arrows inside the
machine.
6
Lower the front of the transfer roller to until
the roller clicks into place.
7
Close the right hand cover.
Note • When closing the right hand cover, apply your
hand in the vicinity of the handle as shown in
the illustration, and then press the cover firmly
toward the machine.
• If the front cover is not closed completely, a
message appears and the machine will remain
paused.
To Next Page
