13 Maintenance
234
17
Close the inner cover.
18
Rotate the lock levers to secure the inner cover
while pressing the cover with the other hand.
19
Close the front cover.
20
Close the right hand cover.
Note • When closing the right hand cover, apply your
hand in the vicinity of the handle as shown in
the illustration, and then press the cover firmly
toward the machine.
• If the front cover is not closed completely, a
message appears and the machine will remain
paused.
Replacing Transfer Roller
Note • To prevent electric shock, always turn off the machine and disconnect the power cable from the
grounded outlet before performing maintenance.
1
Make sure that the <Data> indicator light is off and there are no jobs currently in process.
2
Press the power switch to the [ ] position to
switch the power off.
To Next Page
