Replacing Consumables
233
12
Grasp the handles on top of the transfer belt
unit.
Note • Do not hold the sides of the transfer belt unit.
It may degrade print quality.
13
Align the arrows on the transfer belt unit with
the arrows on the machine.
14
Slide the unit into the machine and stop when
the visible line reaches the machine.
15
Lower the handles.
16
Push the front of the transfer belt unit to
reinstall it in the machine until it stops.
