22 Problem Solving

626

Stapler Faults

This section describes how to clear stapler troubles when the optional finisher is installed.

Perform the procedures on the following pages when copies are not stapled or staples are

bent. Contact Customer Support at dell.com/contactdell if the problem persists after you

have tried the following solutions.

If copies are stapled as shown in the figures below, contact Customer Support at

dell.com/contactdell.

Unstapled

Bent Staple

One side of staple rising up

Staple bent in reverse direction

Flattened staple

Entire staple rising up

Staple rising up with

center pressed in
