13 Maintenance
232
Note • Do not hold the parts shown in the illustration.
9
Slide the blue tab back-and-forth five times to
clean the conductivity temperature depth
sensor.
Note • Be careful not to touch the fusing unit. It can
burn your fingers.
10
Unpack a new transfer belt unit and place the
unit on a level surface.
11
Remove the protective parts shown in the
illustration.
To Next Page
