Replacing Consumables
231
4
Open the front cover.
5
Rotate the lock levers of the inner cover to open
it.
6
Grasp the handle on the front of the transfer
belt unit.
7
Pull out the transfer belt unit until the line on
the unit becomes completely visible.
8
Grasp the handles on the top of the transfer
belt unit. Pull out the unit to remove it from
the machine.
To Next Page
