Replacing Consumables
229
3
Raise the latch of the right hand cover and open
the cover.
4
Hold the fusing unit by the grips on both sides,
and remove the fusing unit from the machine.
5
Take out a new fusing unit from the box.
6
Hold the new fusing unit by the grips on both
sides, and then place the fusing unit onto the
machine.
Note • Hold the fusing unit with both hands so that
you do not drop it.
7
Close the right hand cover.
Note • When closing the right hand cover, apply your
hand in the vicinity of the handle as shown in
the illustration, and then press the cover firmly
toward the machine.
• If the front cover is not closed completely, a
message appears and the machine will remain
paused.
8
Switch on the main power, and then switch on the power.
For information on how to switch on the power and the main power, refer to "Power Source"
(P.34).
