Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-81
Content Address Function
AC drive
Parameters
GGnnH
GG means parameter group, nn means parameter number,
for example, the address of Pr 4-01 is 0401H. Referencing to
chapter 5 for the function of each parameter. When reading
parameter by command code 03H, only one parameter can
be read at one time.
Bit 0-1
00B: No function
01B: Stop
10B: Run
11B: Jog + Run
Bit 2-3 Reserved
Bit 4-5
00B: No function
01B: FWD
10B: REV
11B: Change direction
Bit 6-7
00B: 1st Step Door Open Accel/Decel
01B: 1st Step Door Close Accel/Decel
10B: 2nd Step Door Open Accel/Decel
11B: 2nd Step Door Close Accel/Decel
0000B: 1st Step Speed Frequency
0001B: 2nd Step Speed Frequency
0010B: 3rd Step Speed Frequency
0011B: 4th Step Speed Frequency
0100B: 5th Step Speed Frequency
0101B: 6th Step Speed Frequency
0110B: 7th Step Speed Frequency
0111B: 8th Step Speed Frequency
1000B: 9th Step Speed Frequency
1001B: 10th Step Speed Frequency
1010B: 11th Step Speed Frequency
1011B: 12th Step Speed Frequency
1100B: 13th Step Speed Frequency
1101B: 14th Step Speed Frequency
1110B: 15th Step Speed Frequency
Bit 8-11
1111B: 16th Step Speed Frequency
Bit 12 Select the function of Bit6~11
Command
Write only
2000H
Bit 13-15 Reserved
