Chapter 5 Parameters|VFD-M-D Series
5-82 Revision Jan. 2007, MDE2, SW V1.05
Content Address Function
2001H Reserved
Bit 0 1: EF (external fault) on
Bit 1 1: Reset
2002H
Bit 2 Reserved
Multi-function Input Terminals (COM1~COM4)
Bit 0 COM1
Bit 1 COM2
Bit 2 COM3
Command
Write only
2006H
Bit 3 COM4
Error code:
00: No error occurred
Status monitor
Read only
2100H
01: Over-current (oc)
02: Over-voltage (ov)
03: Overheat (oH)
04: Overload (oL)
05: Overload1 (oL1)
06: External fault (EF)
07: Reserved
08: CPU failure (cF3.3~cF3.8)
09: Hardware protection failure (HPF.1~HPF.4)
10: Current exceeds 2 times rated current during accel (ocA)
11: Current exceeds 2 times rated current during decel (ocd)
12: Current exceeds 2 times rated current during steady state
operation (ocn)
13: Ground Fault (GFF)
14: Reserved
15: CPU failure 1 (cF1)
16: CPU failure 2 (cF2)
17: Reserved
18: Overload (oL2)
19: Reserved
20: Software/password protection (PcdE/Ccde)
21: Reserved
22: Reserved
23: Reserved
