Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-83
Content Address Function
24: Reserved
25: Reserved
26: PG feedback error (PGEr)
27: Door open/close complete signal error (PSEr)
28: Door open time-out (doEr)
2100H
35: Communication time-out (cE10)
Status of AC drive
LED: 0: light off, 1: light up
00: RUN LED
01: STOP LED
02: JOG LED
03: FWD LED
Bit 0-4
04: REV LED
Bit 5~9 Reserved
Bit 10
1: Operation command controlled by
communication interface
Bit 11 1: Parameters have been locked
Bit 12 0: AC drive stops, 1: AC drive operates
Bit 13 1: Jog command
Status monitor
Read only
2101H
Bit 14-15 Reserved
2102H Frequency command (F)
2103H Output frequency (H)
2104H Output current (A)
2105H DC-BUS Voltage (u)
2106H Output voltage (E)
2107H Step number of Multi-Step Speed Operation
2108H The pulse number for the walking distance (c)
2109H Display the walking distance and step speed (x.yy.y)
210AH Power factor angle
210BH Estimated torque ratio
210CH Motor speed (rpm)
210DH PG pulse (low word) /unit time
210EH PG pulse (high word) /unit time
210FH Output power (KW)
2110H Reserved
