Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
5-84 Revision Jan. 2007, MDE2, SW V1.05
Content Address Function
2200H Reserved
2201H User-defined (Low word)
2202H User-defined (High word)
2203H Reserved
2204H Reserved
2205H Reserved
2206H
Display temperature of heatsink (°C)
2207H Reserved
2208H Reserved
Multi-function output terminals MO3~MO6
Status monitor
Read only
Bit0 MO3
Bit1 MO4
Bit2 MO5
2209H
Bit3 MO6
Warning Code
08: auto tuning error (AUE)
09: parameter copy failure (SE1)
10: parameter copy check failure (SE2)
18: overload (oL2)
26: PG feedback error (PGEr)
27: limit signal error (PSEr)
31: illegal function code (cE01)
32: illegal data address (cE02)
33: illegal data value (cE03)
34: slave device failure (cE04)
220AH
35: communication time-out (cE10)
3.6 Exception response:
The AC motor drive is expected to return a normal response after receiving command
messages from the master device. The following depicts the conditions when no normal
response is replied to the master device.
The AC motor drive does not receive the messages due to a communication error; thus,
the AC motor drive has no response. The master device will eventually process a timeout
condition.
