Field Service Ver. 1.0 Apr. 2005 15. Malfunction code
131
ineo 161
ineo 210
Troubleshooting
C0500 Warm-up failure
• The surface temperature of the Fusing Roller does not
reach a given level even after the lapse of a given period of
time during a warm-up cycle.
From room temperature to 100°C : 35 sec.
From 100°C to 140°C : 25 sec.
From 140°C to the completion of
the warm-up cycle : 20 sec.
C0500
Warm-up failure
(for the model having two
Fusing Roller Heater
Lamps)
*ineo 210 only
• The Fusing Roller Thermistor does not detect a predeter-
mined temperature within 30 sec. after a warm-up cycle
has been started and thus the warm-up cycle is not com-
pleted.
• The surface temperature of the Fusing Roller does not
reach a given level even after the lapse of a given period of
time during a warm-up cycle.
From room temperature to 60°C : 4 sec.
From 60°C to 100°C : 2 sec.
From 100°C to 130°C : 1 sec.
From 130°C to 155°C : 0.5 sec.
C0501
Warm-up failure 2
(for the model having two
Fusing Roller Heater
Lamps)
*ineo 210 only
• The Fusing Roller Sub Thermistor does not detect a prede-
termined temperature within 30 sec. after a warm-up cycle
has been started and thus the warm-up cycle is not com-
pleted.
• The surface temperature of the Fusing Roller does not
reach a given level even after the lapse of a given period of
time during a warm-up cycle.
From room temperature to 60°C : 7 sec.
From 60°C to 100°C : 2 sec.
From 100°C to 130°C : 1 sec.
From 130°C to 155°C : 0.5 sec.
C0510
Fusing failure
(abnormally low fusing
temperature)
• The temperature detected by the Fusing Roller Thermistor
remains lower than 120°C (105°C for the model having two
Fusing Roller Heater Lamps) for a given period of time dur-
ing the standby state.
• The temperature detected by the Fusing Roller Thermistor
remains lower than 120°C (105°C for the model having two
Fusing Roller Heater Lamps) for a given period of time dur-
ing a print cycle.
C0511
Fusing failure
(abnormally low fusing
temperature 2)
*ineo 210 only
• The temperature detected by the Fusing Roller Sub Ther-
mistor remains lower than 105°C for a given period of time
during the standby state.
• The temperature detected by the Fusing Roller Sub Ther-
mistor remains lower than 105°C for a given period of time
during a print cycle.
C0520
Fusing failure
(abnormally high fusing
temperature)
• The temperature detected by the Fusing Roller Thermistor
remains higher than 240°C for a given period of time.
C0521
Fusing failure
(abnormally high fusing
temperature 2)
*ineo 210 only
• The temperature detected by the Fusing Roller Sub Ther-
mistor remains higher than 240°C for a given period of
time.
Code Item Description
