15. Malfunction code Field Service Ver. 1.0 Apr. 2005
132
ineo 161
ineo 210
Troubleshooting
C0650
Faulty Scanner Home
Position Sensor
The Scanner Home Position Sensor (PC10) does not go
from HIGH to LOW when the Scanner Motor (M5) is ener-
gized for a given number of steps after the sequence to
bring the Scanner back to its home position has been
started at the end of a scan motion and during re-shading.
The Scanner Home Position Sensor (PC10) does not go
from LOW to HIGH when the Scanner Motor (M5) is ener-
gized for a given number of steps after a scan motion has
been started at the end of a Scanner Home Position Sen-
sor home check scan motion and during re-shading.
C0B60
Bin Switching Motor mal-
function
(Only when the optional
JS-503 is mounted)
Refer to the option service manual (JS-503) for details.
C0B80
Shift Motor malfunction
(Only when the optional
SF-501 is mounted)
Refer to the option service manual (SF-501) for details.
C0F32 Faulty ATDC Sensor
The measurement taken by the ATDC Sensor (UN1) at a
time 2.0 sec. after the Main Motor (M1) has started turning
is less than 5% (greater than 4.63 V).
The measurement taken by the ATDC Sensor (UN1) at a
time 2.0 sec. after the Main Motor (M1) has started turning
is 19% or more (1.41 V or less).
C0F33
Improperly adjusted
ATDC Sensor
The adjustment of the ATDC control voltage is not com-
pleted within 1 sec. after sampling has started of the ATDC
Sensor (UN1) as part of an operation of ATDC Sensor
Automatic Adjustment.
The ATDC Sensor control voltage falls outside the range of
5.39 V to 8.15 V during an operation of ATDC Sensor Auto-
matic Adjustment.
C1038 Engine connection failure
Master Board (PWB-A) to Control Board (PWB-C/C) connec-
tion failure
There is no acknowledge signal transmitted from the Mas-
ter Board (PWB-A) to Control Board (PWB-C/C) for 1.5
sec. or more.
An error command signal is transmitted from the Control
Board (PWB-C/C) to Master Board (PWB-A).
An error status signal is transmitted from the Master Board
(PWB-A) to Control Board (PWB-C/C).
C1200 Faulty ASIC/memory
ASIC/memory (for image and control) fault
A write or read error occurs with SRAM on the Control
Board (PWB-C/C).
Code Item Description
