Controlling Aux Send and Variable Group Send Pan
When Aux busses or Variable Group busses are linked, input
signals are panned across the bus pair. Panning can be con-
trolled from the Input section or from the ACS Aux Sends sec-
tion.
To control panning of Aux bus or Variable Group bus pairs from
the Input section:
1 Do one of the following:
• Display Aux Sends on the input channels.
• Display Variable Group Sends on the input channels.
2 In the Input Encoder Assignment section, press the Aux
switch for the bus pair you want to pan.
• The first press of the Aux switch assigns control of the
send level to the encoder. The switch lights green and the
encoder display shows the odd-numbered send.
• The second press of the Aux switch assigns control of the
send pan to the encoder. The switch lights yellow and the
display shows a “P” before the odd-numbered send.
3 With the Aux switch lit yellow, turn the rotary encoder
knob on each Input Channel or FX Return where you want to
adjust the send pan.
To control panning of Aux bus or Variable Group bus pairs from
the ACS Aux Sends section:
1 Target the channel whose bus pair you want to pan by press-
ing its Select switch. In a linked bus pair, the ACS Aux Send
controls show the following:
• Odd-numbered rotary encoders control send level
• Even-numbered rotary encoders control send pan
2 Turn the even-numbered rotary encoders in the Aux Sends
section to adjust the send pan.
Setting Aux Send Pan and Variable Group Send Pan
to Follow Channel Pan
Panning of the input signal can be set to follow the pan or bal-
ance values of the Input Channel or FX Return feeding the
Aux bus or Variable Group bus.
To set the Aux Send or Variable Group pan to follow Channel pan:
1 Go to the Options page and click the Busses tab.
2 On any linked bus pairs, select the Follows Channel Pan op-
tion. This setting is applied globally to the corresponding Aux
Send or Variable Group Send.
Adjusting Aux Bus and Variable Group
Bus Output Controls
Aux Bus and Variable Group Bus Output
Levels
See “Output Levels” on page 66.
Aux Bus and Variable Group Bus Output
Polarity Invert
See “Output Polarity (Phase) Invert” on page 66.
Aux Bus and Variable Group Bus Output Solo
See “Output Solo” on page 66.
Aux Bus and Variable Group Bus Output
Mute
See “Output Mute” on page 67.
Aux Bus Output Delay
A variable delay (0–250 ms) can be applied to any of the Aux
bus outputs. Variable Group outputs do not have this variable
delay feature.
To apply delay to an Aux bus:
1 Target the Aux bus by pressing its Select switch.
2 Press the ACS Delay rotary encoder to apply the delay to the
bus.
3 Adjust the delay value by turning the Delay rotary encoder.
