Chapter 18: Hardware Inserts 135
Assigning Hardware Inserts from the
Patchbay
To assign a hardware insert from the Patchbay:
1 Go to the Patchbay and click the Inserts tab.
2 In the Inserts page of the Patchbay, click Channels, FX Re-
turns, or Outputs tab.
3 Click in the channel grid to assign the insert input/output
number (listed across the top) to the channel where you want
to assign the insert (listed on the left).
The Patchbay Inserts page shows the name of the channel and
its destination at the current cursor location. The Insert loca-
tion is also displayed in the Inserts section in the Inputs or
Outputs page.
Assigning a hardware insert in the Patchbay Inserts page
