Chapter 5: Diagnostics
5. Diagnostics
Note:
The RHINO2 is not user serviceable. Specialised tools are necessary for the repair
of any RHINO2 component.
5.1 Introduction
An abnormal condition may be indicated by a flash code on the Status output. A Flash Code
is a sequence of flashes, separated by a pause, followed by a repetition of the sequence.
Additionally, Flash Codes may be sounded by connecting a beeper to a suitably
programmed output and setting the Flash Code Beeper parameter (4.4.1.5) to 'Yes'.
Depending on the condition, the scooter may or may not allow driving. In some cases driving
may be allowed but in a reduced speed („limp‟) mode.
5.2 Flash Code Display
To make the most of your existing industry knowledge of products, the RHINO2 has the ability
to display a variety of different flash code types. These may be one of Scooter, Shark, Type 3,
or Type 4. The Diagnostics Report lists the Flash Code type that the controller is currently set to
display. See the following sections for each set of flash code details.
