Dynamic RHINO2

Chapter 5: Diagnostics
115
5.5 Advanced Diagnostics Logs
In addition to the standard diagnostics reports, additional diagnostic information is available
from the controller using the Wizard or HHP. This additional information is extremely useful for
identifying the root cause of any faults, and allows for a faster, more efficient service process.
It will also allow for feedback to be given to the user if their use of the scooter is causing any
issues.
There are two sources of the advanced diagnostics logs; the Usage Counters provide
detailed information on the use of the scooter; the Run-time Readings provide real-time
analysis of the system in operation.
Usage Counters (available in both Wizard and HHP)
Counter
Description
Powered Up Time
The total amount of time (hours) the controller has been turned
on.
Powered Up Count
The number of times the controller has been turned on.
Drive Time
The total amount of time (hours) the controller has been driving
(park brakes disengaged).
Drive Count
The number of times the controller has been driving (number of
times the park brakes have disengaged).
Overcharge Count
The number of times the batteries have been overcharged.
Deep Discharge Count
The number of times the batteries have been deep
discharged.
Run-time Readings (available in HHP – Technician mode only)
Reading
Description
Battery (V)
The voltage of the batteries.
Motor (V)
The voltage being applied to the motor.
Motor (A)
The current being applied to the motor.
Temperature (C)
The internal temperature of the controller.
Throttle (V)
The voltage of the throttle.
