Dynamic RHINO2 User Manual

Chapter 3: Installation and Testing
12
3.1.2 Mounting Orientation
Recommended Mounting Orientation:
The recommended mounting orientations for RHINO2 units are vertical (with connector
side on the bottom) and horizontal (with connector facing upwards or downwards). The
horizontal (with connector facing downwards) mounting orientation is permitted to be
tilted a further 30° for mounting.
Vertical (Connector side on the bottom) Mounting Orientation
Horizontal (Connector facing upwards) Mounting Orientation
Horizontal (Connector facing downwards) Mounting Orientation
30° max
