Dynamic RHINO2 User Manual

Chapter 5: Diagnostics
110
5.2.2 SHARK Flash Codes
Flash
Description
Meaning
1
User Fault / Drive Inhibit
Either a Stop function is active or a Charger Inhibit
condition has occurred.
Release the Stop condition (seat raised etc.)
Disconnect the Battery Charger
• Turn the controller off and then on again.
2
Battery Fault
Battery voltage is either too low or too high.
If you have been driving normally the batteries
may be depleted. Recharge the batteries.
If you are travelling down a slope, the batteries
may be overcharged. Reduce your speed to
minimise the amount of regenerative charging
Check the battery and associated connections
and wiring.
3
Motor Fault
The motor has been exceeding its maximum
current rating for too long, or may be faulty.
Turn the controller off, leave for a few minutes
and turn back on again.
Check the motor and associated connections
and wiring.
4
Current Limit Time-out or
Controller too hot
The motor has been exceeding its maximum
current rating for too long.
The scooter may have stalled. Turn the
controller off, leave for a few minutes and turn
back on again.
The motor may be faulty. Check the motor and
associated connections and wiring.
5
Park Brake Fault
Either a park brake release switch is active or the
park brake is faulty.
Check the park brake and associated
connections and wiring.
Ensure any associated switches are in their
correct positions.
6
unused
7
Throttle Fault
The Throttle is out of neutral when turning the
controller on. The throttle or speed limit pot, or their
associated wiring may be faulty.
Ensure the throttle is in neutral when turning the
controller on.
The Throttle may require re-calibration.
Check the throttle and speed pot and
associated connections and wiring.
8
System Fault
The controller may have an internal fault.
Check all connections and wiring.
