Chapter 1: Introduction to the RHINO2
1. Introduction to the RHINO2
The RHINO2 family of scooter controllers provides a reliable, refined, cost-effective control
solution for most mobility scooters and includes:
DS90 - RHINO2 90A Controller
DS90-ACT - RHINO2 90A Controller with actuator
DS120 - RHINO2 120A Controller
DS120-ACT - RHINO2 120A Controller with actuator
DS160 - RHINO2 160A Controller
DS160-ACT - RHINO2 160A Controller with actuator
RHINO2 – DS90 and DS120 RHINO2 – DS160
90, 120 and 160A models provide the power you want when you need it
Programmable acceleration curves, improved rollback on slopes, and improved motor
matching algorithms ensuring better curb-climbing and hill-starting capabilities
Speed reduction wiper (SRW) technology provides a seamless speed reduction in curves
for extra stability
Throttle Dual Decode (requires ISO compliant speed pot) provides extra safety in case of
a throttle failure, and allows OEMs to comply with the new requirements of ISO7176-14
(2008).
Intelligent motor and battery management providing automatic power flow optimisation,
auto battery configuration, 5V and 12V battery capacity outputs (Trucharge) and in-
depth battery logging and analysis tools
Support for a range of battery types, multi-function pins and flexible drive inhibits
Advanced diagnostics and servicing tools, including event and drive time logging, and
programmable servicing scheduler
2 Drive profiles, brake and reverse lights, reversing beeper and electronic park brake
release
IP54 ingress protection
A separately available aluminium terminal cover provides increased protection to IP55
when fitted
Compliant with EU Directive 2002/95/EC of 27 Jan. 2003 – restrictions on use of Hazardous
Substances (RoHS)
Optional single actuator output (with Wig-wag or dedicated switch activation).
