Chapter 3
:
Inst
allation and Testing
26
Example of Charger S
ocket wiring for an
Off-b
oard charger (s
hown using the tiller c
onnector)
Note:
The inhibit pin is a Multi-function input and can be used for an alterna
tive function if
a charger is not plugged into this pin.
Warning:
A suitable fuse, with a maximum rating of 8A, must be installed in the Battery
Positive wire to protect the scooter
’s
wiring. Connect the fuse as close as practical
to the controller connector to minimise the length of unprotected wiring.
