10. TECHNICAL DATA
10.1. Transmitter
Display LC-Display, 4 lines, 20 characters
Keyboard 4 keys
Enclosure
IP 66; Aluminum;
wall mounted indoor use only or environmental enclosure
Operating
Temperature
-4…140° F (-20…60° C)
Storage Temperature -4…158° F (-20…70° C)
Maximum Humidity 90% (non-condensing)
Maximum Operating
Altitude
AC device: 2000 m above sea level
Power Supply 100…240V AC, ±10% 47…63Hz or 10…36V DC, ±15%, 5% residual ripple
Power Consumption
AC: max. 40 VA, typically: 30VA
DC: max. 30 W, typically: 8 W
Operating
Conditions
Protection class I
Overvoltage category I
Pollution degree 2
Outputs Analog Four 4…20 mA active channels, load <550 Ohms
Outputs Digital
Four relays 60V DC 1A or 30V AC 1A 200 Hz max.; normally open or normally closed
Two pulse/frequency outputs; 24V DC
Inputs Analog Four 4…20 mA input channels; 1 channel reserved for level
Inputs Digital Two inputs 30V DC max.
Communication Modbus RTU 485; Modbus TCP Ethernet 10/100 Mbps RJ45
Programming Port
Webserver using standard web browser via WiFi or Ethernet;
English, French, German, Spanish, Polish, Czech, Russian or Japanese languages
Data Logging 16 GB Micro SD card; 12 months of storage; file transfer through web browser
Channel/Pipe Shapes Round radius, U-shape, rectangular, trapezoid, egg-shape, custom channel
CE Compliance
Low Voltage Directive, 2014/35/EU, EMC 2014/30/EU, Radio Equipment Directive 2014/53/EU,
RoHS 2 2011/65/EU, 2015/863/EU
Certification Option
cCSAus general area indoor use: CAN/CSA-C22.2 No. 61010-1-12, UPD1:2015, UPD2:2016,
AMD1:2018; UL 61010-1 Third Edition (2012), AMD1:2018
Technical Data
Page 107 March 2021 HYB-UM-03155-EN-03
