7.6.2. Setting
Settings for selection of parameters and corresponding units (SI units or displayed units) for download-file under
Download selectable.
Setting
Setting Description
Use SI units
Tick checkbox to download data in SI units.
Use Display units
Tick checkbox to download data in displayed units.
Before you start to choose the data, please check and define the displayed units in the main
menu Settings under Displayed Units.
All Data
Tick checkbox to select all data shown below.
Do not tick if you want to select single parameters.
Insert Unit in CSV Header
Tick checkbox to display unit in csv-file.
In the following list you can also specify single parameters (Length, Time, Time, Q, Velocity,
Volume, Temperature, Unitless, Concentration, Signal, Voltage…) for download by ticking
the corresponding checkboxes.
OTE: N The list comprises and shows all possible parameters that can be set for all measuring
systems using the specified transmitter type and not only for the connected system.
7.7. Parameter - Parameterization
Parameter
Geometry Measurement Range Calibration
Replacement Temperature
The menu provides further options for
• Definition of cross-section parameters
• Settings for level measurement
• Parameter setting for discharge calculation
• Calibration
• Replacement function for discharge calculation
• Setting a temperature offset to a reference measurement
Programming
Page 41 March 2021 HYB-UM-03155-EN-03
