dynasonics Badger Meter IS-6000 Doppler User Manual

7.7.6. Temperature
 Replacement
Setting Description
Temperature-Offset
(Water)
> Default setting: 0 °C. Enter the difference between a reference temperature measurement and
the integrated temperature measurement of the area velocity sensor.
Example: Tref = 20 °C and Tint = 19 °C; temperature offset = +1 °C
7.8. I/Os – Digital and analog inputs and outputs
 I/Os
 Analog In  Analog Out  Digital In  Digital Out
 Users values
Parameterization for analog and digital in- and outputs, pulse output and user-defined outputs.
7.8.1. Analog Input
Parameterization and settings for analog connected sensors (water level sensors, sensors for user defined parameters).
Programming
Page 62 March 2021HYB-UM-03155-EN-03
