Dynatest FWD - Page 55

2017.06.19 FwdMan2.8.17.docx 5-43
Table 2 (UUFWDUU ONLY!)
MASS of WEIGHT
Load Range (approx.)
kg
(lbs)
kPa/300
kN
lbf
350
(770)
565-1700
40-120
9,000 -27,000
250
(550)
380-1200
27-85
6,000 -18,500
150
(330)
225-700
16-50
3,500 -11,000
50
(110)
100-270
7-20
1,500 -4,400
Table 3 (HWD ONLY!)
MASS of WEIGHT
k (approx.)
kg
(lbs)
kPa/300
kN
lbf
740
(1650)
225
16
3500
540
(1200)
165
12
2700
340
(755)
105
7.5
1700
240
(535)
72
5.2
1150
Before the drop height is calculated, it is necessary to select a weight setup (240, 340, 540 or
740 kg). To do this, use the following Table 4 showing the usable load ranges for each weight
setup:
Table 4 (HWD ONLY!)
MASS of WEIGHT
Load Range (approx.)
kg
(lbs)
kPa/300
kN
lbf
740
1650
1600-4500
115-320
26,000-70,000
540
1200
1200-3300
85-240
19,000-54,000
340
755
770-2100
55-150
12,300-34,000
240
535
530-1450
38-105
8,600-23,000
----------------------------------------------------------------------------------------------------------------
Example 1 (UUFWDUU ONLY!):
If you want an approx. peak load of e.g. 11,000 lbf. (50 kN), then it can be seen from Table 2
that
the 250 kg (550 lb.) weight setup
OR the 350 kg (770 lb.) setup
can be used, and then Table 1 gives:
250 kg (550 lb.): k = 935 lbf
OR 350 kg (770 lb.): k = 1,350 lbf
