1.
[Main menu] Press the button.
ð
The ‘Main menu’ screen is displayed.
2. [Operating mode] - select.
ð
The screen for setting the [Operating mode] is displayed.
3. [Pulse] - select.
4.
[ Press the Next button] .
ð
Screen for setting the ‘pulse interval’ is displayed.
5. Enter the quantity in litres (before the decimal point) using the scrollbar
.
6. ‘Select the quantity details in the decimal point position’.
7. Enter the quantity in litres (after the decimal point) using the scrollbar
.
8.
[Press the Next button]
.
ð
Screen for selecting the ‘pulse memory’ is displayed.
9. ‘Select pulse memory’.
ð
If the ‘pulse memory’ is activated, a ü is displayed in the selection box.
10.
[Press the Next button] .
ð
Screen for setting the‘Solution concentration’ is displayed.
11. Enter the concentration in % (before the decimal point) using the scrollbar
.
12. ‘Select the concentration in the decimal point position’.
13. Enter the concentration in % (after the decimal point) using the scrollbar
.
14.
Pressing the button saves and returns to the[Operating mode].
15.
Pressing the button returns to the [Main menu].
16.
Pressing the button returns to the [Operating display].
Commissioning
129 Rev. 2-05.2018
