ESIM384 Installation and Conguration Manual v1.1
Enable parallel data
transmission
EKB2
Menu path:
OK → iiii → OK → MS SETTINGS → OK → IP SETTINGS → OK → PARAL.DS.MODE → OK →
ENABLE → OK
Value: iiii – 4-digit installer code.
EKB3/
EKB3W/
EWKB4
Enter command 96, parameter number and parameter status value:
96 01 1 #
Example: 96011#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
Disable parallel data
transmission
EKB2
Menu path:
OK → iiii → OK → MS SETTINGS → OK → IP SETTINGS → OK → PARAL.DS.MODE → OK →
DISABLE → OK
Value: iiii – 4-digit installer code.
EKB3/
EKB3W/
EWKB4
Enter command 96, parameter number and parameter status value:
96 01 0 #
Example: 96010#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
30.2.2. Voice Calls and SMS
The system supports up to 3 monitoring station phone numbers for communication with the alarm system by Voice Calls or SMS communi-
cation method using Ademco Contact ID or Cortex SMS data format respectively. Tel. Number 1 is mandatory, the other two can be used as
backup phone numbers and are not necessary. The supported phone number formats are the following:
• International (with plus) – The phone numbers must be entered starting with plus and an international country code in the fol-
lowing format: +[international code][area code][local number], example for UK: +44170911XXXX1. This format can be used when
setting up the phone number by ELDES Conguration software.
• International (with 00) – The phone numbers must be entered starting with 00 and an international country code in the following
format: 00[international code][area code][local number], example for UK: 0044170911XXXX1. This format can be used when setting
up the phone number by EKB2/EKB3/EKB3W/EWKB4 keypad.
• Local – The phone numbers must be entered starting with an area code in the following format: [area code][local number], example
for UK: 0170911XXXX1. This format can be used when setting up the phone number by EKB2/EKB3/EKB3W/EWKB4 keypad and EL-
DES Conguration software.
To set up the system for data transmission via Voice Calls or SMS, please follow the basic conguration steps:
1. Enable MS Mode parameter (see 30. MONITORING STATION).
2. Set 4-digit Main Account number (see 30. MONITORING STATION).
3. Set Tel. Number 1... 3.
Set monitoring station
phone number
EKB2
Menu path:
OK → iiii → OK → MS SETTINGS → OK → VOICE CALLS/SMS ST → OK → TEL. NUMBER 1... 3 →
OK → ttteeellnnuumm → OK
Value: iiii – 4-digit installer code; ttteeellnnuumm – up to 15 digits monitoring station phone
number.
EKB3/
EKB3W/
EWKB4
Enter parameter 26, phone number slot and phone number:
26 ps ttteeellnnuumm #
Value: ps – phone number slot, range – [01... 03]; ttteeellnnuumm – up to 15 digits monitor-
ing station phone number.
Example: 26010044170911XXXX1#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
