EN
ESIM384 Installation and Conguration Manual v1.1
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
Enable Force attribute
for individual zone
EKB2
Menu path:
On-board zone: OK → iiii → OK → ZONES → OK → ONBOARD ZONES → OK → ZONE 1... 16 → OK
→ FORCE → OK → ENABLE → OK
Wireless zone: OK → iiii → OK → WIRELESS ZONES → OK → WIRELESS ZONES 1... 4 → OK →
WIRELESS ZONE 13... 80 → OK → FORCE → OK → ENABLE → OK
Keypad zone: OK → iiii → OK → ZONES → OK → KEYPAD ZONES → OK → 1ST... 4TH KEYPAD
ZONE → OK → FORCE → OK → ENABLE → OK
EPGM1 zone: ... → EPGM1 ZONES 1-16... EPGM1 ZONES 17-32 → OK → 1... 8. EPGM1 ZONE 1...
32 → OK → FORCE → OK → ENABLE → OK
Value: iiii – 4-digit installer code.
EKB3/
EKB3W/
EWKB4
Enter parameter 82, zone number and parameter status value:
82 nn 1 #
Value: nn – zone number, range – [01... 80].
Example: 82061#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
Disable Force
attribute for
individual zone
EKB2
Menu path:
On-board zone: OK → iiii → OK → ZONES → OK → ONBOARD ZONES → OK → ZONE 1... 16 → OK
→ FORCE → OK → DISABLE → OK
Wireless zone: OK → iiii → OK → WIRELESS ZONES → OK → WIRELESS ZONES 1... 4 → OK →
WIRELESS ZONE 13... 80 → OK → FORCE → OK → DISABLE → OK
Keypad zone: OK → iiii → OK → ZONES → OK → KEYPAD ZONES → OK → 1ST... 4TH KEYPAD
ZONE → OK → FORCE → OK → DISABLE → OK
EPGM1 zone: ... → EPGM1 ZONES 1-16... EPGM1 ZONES 17-32 → OK → 1...8. EPGM1 ZONE 1...
32 → OK → FORCE → OK → DISABLE → OK
Value: iiii – 4-digit installer code.
EKB3/
EKB3W/
EWKB4
Enter parameter 82, zone number and parameter status value:
82 nn 0 #
Value: nn – zone number, range – [01... 80].
Example: 82110#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
Enable/disable
Shared attribute for
individual zone
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
Set Delay,s attribute
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
Enable/disable Delay
becomes Instant in
Stay mode attribute
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
