ESIM384 Installation and Conguration Manual v1.1

Outputs Faults Users AdvancedZones

Temperature

Sound Settings

Speech volume

Sound volume 30 %

Speech on re

30 %

Quick Menu

Quick arm

Panic

Fire

About

Model:

EWKB5

Connected to:

ESIM384, FW: V1.0.17

Firmware version: V0.0

Service mode

Service mode

LCD Stteings

Brightness

Wake up time 10 s

75 %
