CONFIGURATION SCREENS
Options Configuration
2-9317-372-00-0 Bravo™ 8105 Programming and Operations Guide 9-93
Miscellaneous UPS is the Uninterruptable Power Supply. It provides power to the machine when
a power failure occurs.
SMEMA is the communications protocol standardized by the industry.
Programmable Output Relays should not be used in conjunction with SMEMA as
SMEMA uses two (2) of the three (3) available outputs. The Programmable
Outputs are configured in a separate screen. Refer to A.
Exit Photocell is selected when the photocell is installed at the Unload End of the
machine. It determines if boards are lost or jammed in the machine.
The Light Tower is a standard feature on the machine. It is configured in a
separate window.
