CONFIGURATION SCREENS
Programmable Output Relay Configuration
2-9317-372-00-0 Bravo™ 8105 Programming and Operations Guide 9-95
Programmable Events
Continued
Machine in Manual
The relay state changes when the machine is operating in Manual Mode.
Auto–Start in Progress
The machine is in the process of a controlled start up.
Auto–Stop in Progress
The machine is in the process of a controlled shut down.
Ready – No PCBs in Machine
The relay state changes when the machine is at a Ready state but no PCBs
are inside the machine.
Ready – PCBs in Machine
The relay state changes when the machine is at a Ready state and PCBs are
inside the machine.
PCBs in Machine
The relay state changes when ever there are PCBs in the machine, regardless
of Ready State.
Conveyor Running
The relay state changes when the conveyor is On.
Conveyor Width Adjust Active
The relay state changes when ever the optional Pin Chain Conveyor is in the
process of a width adjust operation.
