TECHNICAL DATA
Electrical Information
2-26 Bravo™ 8105 Programming and Operations Guide Rev. 2
2
Conveyor
Specifications Table
Conveyor
Speed
3 to 178 cm/min (1 to 70 in./
min)
Speed
Accuracy
+
0.25 cm/min (+0.1 in./min)
Rail
Parallelism
+
0.5 mm (+0.020 in.)
Process Width
Mesh Belt 457 mm (18 in.)
Pin Chain 50 mm to 432 mm (2 in. to 17
in.)
Process Height
Mesh Belt 64 mm (2.5 in.)
Pin Chain 32 mm (1.25 in.) Above
25 mm (1.0 in.) Below
Conveyor Height from Floor (Adjustable)
Mesh Belt 813 mm (32 in.) to 965 m (38
in.)
Pin Chain 838 mm (33 in.) to 991 mm
(39 in.)
Torque Limit on Motor
Mesh Belt 11.3 Newton-m (100 in.-lb)
Pin Chain 11.3 Newton-m (100 in.-lb)
