Section C: System Dimensions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Physical
Characteristics Table
System Length 494 cm (194.5 in.)
System Width 116 cm (46.0 in.)
Height 145 cm (57.0 in.)
Mesh Belt Conveyor
Height
81.3 cm to 96.5 cm (32.0 in. to
38.0 in.)
Pin Chain Conveyor
Height
83.8 cm to 99.1 cm (33.0 in. to
39.0 in.)
Access Clearance Front 67.3 cm (26.5 in.)
Access Clearance Rear 25.4 cm (10.0 in.)
Machine Weight Per Leg ∼395 kg (870 lbs)
Machine Weight Total ∼2359 kg (5200 lbs)
Noise Levels All positions at or below 70 dbA
